Infrared sensor automatically turns dryer on when hands are held under air-outlet opening and across path of sensor. Remove hands from path of sensor and dryer stops. Electronic sensor has automatic shutoff approximately 85 seconds after dryer turns on if an inanimate object is placed across air-outlet opening. After inanimate object is removed, electronic sensor automatically resets itself and dryer operates normally
5-Year Limited Warranty — In addition to Bobrick’s one-year guarantee, Bobrick extends a limited 5-year warranty from the date of purchase on all parts for model B-7125. This warranty is limited to the repair or exchange of defective parts at the option of Bobrick and is only extended to the original owner of the installed unit against defects in factory workmanship or material under normal use and service.
Brushed Satin Unit is equipped with single outlet for efficient dry time. The unit is uniquely designed to have a sound pressure level of 75dB(A) measured at 39" (1 meter) from source. The unit is CE marked, cULus Listed..
MATERIALS:
Cover — 18-8, Type-304 stainless steel 1.2mm thick with #4 satin-finish vertical grain. Air-inlet is vandal-resistant. Cover projects no more than 4" (100mm) from wall and is secured to mounting base with two recessed socket button head cap screws.
Mounting Base — 1.5mm SECC punched and formed.
Motor — Brushless 24Vdc with built in thermal protection. Ball bearings. Operates at 40,000 RPM.
Blower — Backward curved radial bladed impeller in polycarbonate housing.
Electronic Control — Infrared sensor automatically turns dryer on when hands are held under air-outlet opening and across path of sensor. Remove hands from path of sensor and dryer stops. Electronic sensor has automatic shutoff approximately 85 seconds after dryer turns on if an inanimate object is placed across air-outlet opening. After inanimate object is removed, electronic sensor automatically resets itself and dryer operates normally.
Product Code | Colour | Height (mm) | Width (mm) | Projection/Depth (mm) |
B-7125 | Brushed Satin | 274 | 319 | 98 |
INSTALLATION HEIGHTS
Installation Heights are from the floor to bottom of dryer | |
Men | 1170mm |
Women | 1120mm |
Children aged 4 - 7 | 810mm |
Children aged 7 - 10 | 910mm |
Children aged 10 - 13 | 1020mm |
Children aged 13 - 17 | 1120mm |
Disabled Users | 940mm |
Q. Is the warranty an on-site Warranty?
A. No, if your hand dryer becomes faulty during the warranty period it will need to be returned to the manufacturer for either a repair or replacement. The warranty on any product is offered by the manufacturer and not by ourselves however we will assist with any problems that may occur during this period.
"
