Zip Instantaneous Water Heater
- 3 Wattages to choose
- Easy to install
- Instant hand wash unit
- Flow adjustment control
Zip ES Instant Water Heater
The ES Instant Water Heater is designed to provide warm water (38º) for hand wash only in areas where space is limited.
Heating power controlled electronically for temperature stabilisation
Outlet temperature can be preset inside the unit between 30˚C and 45˚C (factory set at 38˚C), please note that if you increase the water temperature then the flow rate will be reduced.
Flow adjustment control, preset for a temperature increase of 25k
Stainless steel bare-wire heating system for very quick response
Double pole thermal cut-out protection
Supplied with 700mm of pre-wired cable
Easy to install with improved wall bracket
WRAS approval and CE endorsed
Taps required with this unit are M22 or M24 compatible as they must be able to accept the flow restrictor aerator that is supplied with the unit.
ErP A Rated
ES3 2.8 kW
ES4 4.4 kW
ES6 5.5 kW
| Product Code | ES3 | ES4 | ES6 |
| Pressure rating | 10 Bar | ||
| Element type | Bare Wire | ||
| Supply voltage | 1/N/PE 230V~ | ||
| Nominal power rating @ 230V | 2.8kW | 4.4kW | 5.5kW |
| Nominal current @ 230V | 12A | 19A | 24A |
| Temperature adjustment (installer) | 30°C - 45°C | ||
| Maximum inlet temperature | 70°C | ||
| Factory set temperature | 38°C | ||
| Factory set flow rate 38°C | 1.5 litres/min | 2.4 litres/min | 3.0 litres/min |
| Maximum temperature increase @ 230V and a flow rate of: | |||
| 2.0 litres/min | 20°C | 31°C | 39°C |
| 2.5 litres/min | 16°C | 25°C | 31°C |
| 3.0 litres/min | 13°C | 21°C | 26°C |
| 3.5 litres/min | 11°C | 18°C | 22°C |
| 4.0 litres/min | 10°C | 16°C | 20°C |
| Switch on flow rate | 1.2 litres/min | 1.5 litres/min | 1.5 litres/min |
| Switch off flow rate | 1.0 litres/min | 1.3 litres/min | 1.3 litres/min |
| Required specific water resistance @ 15°C | >1100 ohm.cm | >800 ohm.cm | >800 ohm.cm |
| Capacity | 0.2 litres | ||
| Filled weight | 1.5kg | ||
| Water connection | 1/2”BSP | ||
| Dimensions (H x W x D) | 135mm x 186mm x 87mm | ||
| Protection class (IEC 529) | IP25 | ||
